Weld-On Pad Eyes – PELP
Manufactured using only heat certified Australian Steel.
- Forged from G300 Mild Steel – AS3679.1 Grade 300PLUS
- Weld procedure included
- Welding shall always be carried out by a qualified person to AS1554.1:2011
| Type | Working Load Limit (t) | B | C | D | E | Weight (kg) | Product Code | CAD |
|---|---|---|---|---|---|---|---|---|
| Pad Eye | 0.4 | 28 | 23 | 13.75 | 42 | 0.18 | PELP040 | Register |
| Pad Eye | 0.8 | 34 | 28 | 16.5 | 53.75 | 0.32 | PELP080 | Register |
| Pad Eye | 1.6 | 44 | 33 | 20 | 61.75 | 0.62 | PELP160 | Register |
| Pad Eye | 2.5 | 57 | 38 | 24 | 67 | 0.93 | PELP250 | Register |
