Codipro Double Swivel Lifting Ring (MEGA.DSS+)
The universal lifting ring MEGA.DSS+ is a double swivel ring for lifting particularly heavy loads. It is composed of a GRADUP lifting ring designed for rotations under load. Its double swivel ensures perfect alignment with the sling. The lifting ring can swivel 180° but has a rotating range of 360°. It can be used for any lifting configuration (straight lift, with angle, tilting, rotating).
The universal lifting ring MEGA.DSS+ is approved for all lifting configurations from 0° to 90°, designed for use in a temperature range from -20°c to +200°c and carries various markings, including CE, WLL and tightening torque. It is manufactured in compliance with the REACH regulation.
- Standard metric and UNC threads available: M 64 to M 100 – WLL from 30 t to 70 t, UNC 2’’3/4 to UNC 4″ – WLL from 66,000 lbs to 154,000 lbs
- Safety factor 4:1 and 5:1
- Swiveling under load
- 360° rotation – 180° swivel
- Complies with the Machinery Directive 2006/42/CE
- Manufactured in compliance with the EN 1677-1 norm
- Individual traceability number
| Reference | Diameter | SF 5:1 WLL (t) | SF 4:1 WLL (t) | Standard L1 (mm) | Torque (Nm) | S (mm) | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | F (mm) | G (mm) | Weigh (kg) | CAD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MEGA.DSS+ M 64 UP | M 64 (x6) | 30,00 | 35,00 | 100 | 600 | 36 | 127 | 64 | 140 | 186 | 143 | 278 | 69 | 42,0 | Register |
| MEGA.DSS+ M 72 UP | M 72 (x6) | 35,00 | 40,00 | 110 | 700 | 36 | 127 | 64 | 140 | 186 | 143 | 278 | 69 | 43,0 | Register |
| MEGA.DSS+ M 72x4 UP | M 72 (x4) | 35,00 | 40,00 | 110 | 700 | 36 | 127 | 64 | 140 | 186 | 143 | 278 | 69 | 43,0 | Register |
| MEGA.DSS+ M 80 UP | M 80 (x6) | 40,00 | 50,00 | 120 | 800 | 36 | 127 | 64 | 140 | 186 | 143 | 278 | 69 | 44,5 | Register |
| MEGA.DSS+ M 90 UP | M 90 (x6) | 50,00 | 60,00 | 135 | 900 | 36 | 127 | 64 | 140 | 186 | 143 | 278 | 69 | 46,5 | Register |
| MEGA.DSS+ M 100 UP | M 100 (x6) | 60,00 | 70,00 | 150 | 1000 | 36 | 127 | 64 | 140 | 186 | 143 | 278 | 69 | 49,0 | Register |
| Reference | Diameter | SF 5:1 WLL (t) | SF 4:1 WLL (t) | Standard L1 (mm) | Torque (ft/lb) | S (mm) | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | F (mm) | G (mm) | Weigh (kg) | CAD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MEGA.DSS+ U 275 UP | UNC 2’’ 3/4-4 | 66,000 | 77,000 | 105 | 520 | 36 | 127 | 64 | 140 | 186 | 143 | 278 | 69 | 42,5 | Register |
| MEGA.DSS+ U 300 UP | UNC 3" -4 | 77,000 | 88,000 | 115 | 520 | 36 | 127 | 64 | 140 | 186 | 143 | 278 | 69 | 43,0 | Register |
| MEGA.DSS+ U 325 UP | UNC 3’’ 1/4-4 | 88,000 | 110,000 | 125 | 590 | 36 | 127 | 64 | 140 | 186 | 143 | 278 | 69 | 44,5 | Register |
| MEGA.DSS+ U 350 UP | UNC 3" 1/2-4 | 88,000 | 110,000 | 135 | 665 | 36 | 127 | 64 | 140 | 186 | 143 | 278 | 69 | 46,0 | Register |
| MEGA.DSS+ U 375 UP | UNC 3’’ 3/4-4 | 110,000 | 132,000 | 145 | 740 | 36 | 127 | 64 | 140 | 186 | 143 | 278 | 69 | 47,0 | Register |
| MEGA.DSS+ U 400 UP | UNC 4" -4 | 132,000 | 154,000 | 150 | 740 | 36 | 127 | 64 | 140 | 186 | 143 | 278 | 69 | 49,0 | Register |
